三列滿裝滾子軸承
作者： 發布時間：2016-02-20 瀏覽次數：3609
| 型號 | INA 型號 | 外形尺寸 | 基本負荷(KN) | 極限轉速(r/min) | 重量(KG) | |||||
| d | D | B | rsmin | s | 動 | 靜 | ||||
| 3NCF6906V | SL14906 | 30 | 47 | 30 | 0.3 | 0.7 | 42 | 80 | 6500 | 0.16 |
| 3NCF6907VX2 | SL14907 | 35 | 55 | 32 | 0.6 | 0.7 | 53 | 94 | 5500 | 0.28 |
| 3NCF6907VX2-1 | F-91443 | 35 | 55 | 44 | 0.6 | 1 | 84 | 170 | 5500 | 0.41 |
| 3NCF5908VX2 | SL14908 | 40 | 62 | 32 | 0.6 | 0.7 | 63 | 107 | 5000 | 0.4 |
| 3NCF6909VX2 | SL14909 | 45 | 68 | 36 | 0.6 | 0.7 | 80 | 160 | 4600 | 0.48 |
| 3NCF6910VX2 | SL14910 | 50 | 72 | 36 | 0.6 | 0.7 | 84 | 165 | 4300 | 0.52 |
| 3NCF5911VX2 | SL14911 | 55 | 80 | 36 | 1 | 0.7 | 97 | 199 | 3700 | 0.71 |
| 3NCF6912VX2 | SL14912 | 60 | 85 | 40 | 1 | 0.7 | 102 | 216 | 3500 | 0.73 |
| 3NCF6913VX2 | SL14913 | 65 | 90 | 44 | 1 | 1 | 124 | 250 | 3200 | 1.08 |
| 3NCF5914VX2 | SL14914 | 70 | 100 | 44 | 1 | 1 | 142 | 265 | 3200 | 1.1 |
| 3NCF5916VX2 | SL14916 | 80 | 110 | 44 | 1 | 1 | 150 | 300 | 2900 | 1.25 |
| 3NCF5918VX2 | SL14918 | 90 | 125 | 52 | 1.1 | 1.5 | 205 | 425 | 2500 | 1.95 |
| 3NCF5920VX2 | SL14920 | 100 | 140 | 59 | 1.1 | 2 | 260 | 550 | 2200 | 2.85 |
| 3NCF5922VX2 | SL14922 | 110 | 150 | 59 | 1.1 | 2 | 270 | 600 | 2100 | 3.1 |
| 3NCF5924VX2 | SL14924 | 120 | 165 | 66 | 1.1 | 3 | 305 | 660 | 1900 | 4.2 |
| 3NCF5926VX2 | SL14926 | 130 | 180 | 73 | 1.5 | 4 | 355 | 770 | 1700 | 5.6 |
| 3NCF5928VX2 | SL14928 | 140 | 190 | 73 | 1.5 | 4 | 370 | 830 | 1600 | 6 |
| 3NCF5930VX2 | SL14930 | 150 | 210 | 88 | 2 | 4 | 560 | 1230 | 1500 | 9.5 |
| 3NCF5932VX2 | SL14932 | 160 | 220 | 88 | 2 | 4 | 580 | 1330 | 1400 | 10 |
| 3NCF5934VX2 | SL14934 | 170 | 230 | 88 | 2 | 4 | 600 | 1390 | 1300 | 10.5 |
| 3NCF5936VX2 | SL14936 | 180 | 250 | 101 | 2 | 4 | 780 | 1810 | 1300 | 15.5 |
| 3NCF5938VX2 | SL14938 | 190 | 260 | 101 | 2 | 4 | 800 | 1900 | 1200 | 16.2 |
| 3NCF5940VX2 | SL14940 | 200 | 280 | 116 | 2.1 | 5 | 940 | 2220 | 1100 | 22.4 |
